DoALL C-5650SA Semi-Automatic Bandsaw

The DoALL SA series is a line of machines designed and built for general purpose sawing operations. Ideal for jobs in manual (semi-automatic) mode. For ease of use these machines are already equipped with a standard variable vice pressure control, worklight and toolbox.



Standard Equipment

  • PLC control for all electric and hydraulic functions.
  • Idler wheel motion detector and band break switch.
  • Hydraulic band tension.
  • Rapid saw head approach by pushbutton.
  • Carbide inserts with roller bearings.
  • Manual length setting with hydraulic lift roller.
  • Variable vice pressure control.
  • Automatic chip conveyor.
  • Power driven band brush.
  • Flushing hose for machine cleaning.
  • Worklight.
  • One set of tools in tool box.
  • One roller conveyor.
  • Adjustable work height setting.



SPESIFIKASI DoALL C-5650SA Semi-Automatic Bandsaw

Max round 550 mm
Min round 10 mm
Max rectangular (mm) 560 x 500H
Min rectangular (mm) 10 x 10H
Blade (mm)  41 x 1,3 x 5450
 Band speed (m/min) 20, 35, 50, 65, 80
Band drive motor  5,5 kW
Material pass line 750 mm
Dimensions (L x W x H) 1450 x 3000 x 1800
Weight 2600 kg
