Bowers Digital Bore Gauge NEW XT3 Series

Segera Hubungi Kami :

(62) 778 408 6403

sales@lfc.co.id

SPESIFIKASI Bowers Digital Bore Gauge NEW XT3 Series

Bowers Ultima Bore Gauge - Sets without Sylvac Display Ordering Guide:


Code No.Range (inch)Accuracy (inch)Depth (inch)Setting Ring (inch)
XTD8i-XT3 5/16-3/8 0.00015 2.28 0.3125
XTD80i-XT3 3 1/4-4 0.00020 3.94 3.250
XTD6i-XT3 1/4-5/16 0.00015 2.28 0.3125
XTD65i-XT3 2 5/8-3 1/4 0.00020 3.15 2.625
XTD5i-XT3 0.200-0.250 0.00015 0.70 0.2000
XTD50i-XT3 2-2 5/8 0.00020 3.15 2.625
XTD4i-XT3 0.160-0.200 0.00015 0.70 0.1600
XTD3i-XT3 0.120-0.160 0.00015 0.47 0.1600
XTD35i-XT3 1 3/8-2 0.00015 3.15 1.375
XTD2i-XT3 0.100-0.120 0.00015 0.35 0.1000
XTD275i-XT3 11-12 0.00035 4.65 11.000
XTD25i-XT3 1-1 3/8 0.00015 2.62 1.375
XTD250i-XT3 10-11 0.00035 4.65 11.000
XTD225i-XT3 9-10 0.00030 4.65 9.000
XTD20i-XT3 3/4-1 0.00015 2.62 0.750
XTD200i-XT3 8-9 0.00030 4.65 9.000
XTD1i-XT3 0.080-0.100 0.00015 0.35 0.1000
XTD175i-XT3 7-8 0.00030 4.53 7.000
XTD16i-XT3 5/8-3/4 0.00015 2.44 0.750
XTD150i-XT3 6-7 0.00030 4.53 7.000
XTD12i-XT3 1/2-5/8 0.00015 2.44 0.500
XTD125i-XT3 5-6 0.00025 4.53 5.000
XTD10i-XT3 3/8-1/2 0.00015 2.28 0.500
XTD100i-XT3 4-5 0.00025 4.53 5.000



Dapatkan Penawaran Harga

Silahkan isi formulir di bawah ini untuk mendapatkan penawaran harga terbaik dari tim kami,

Bowers Digital Bore Gauge NEW XT3 Series are optimized for measuring precision bore on fast paced production line, under laboratory of either manual or fully automated system. The Bowers Bore gauges manufactured according to DIN 863, part 4 to accurately displays resolutions up to 0.0001mm. The clever bore gage is engineered with Tungsten carbide measuring faces on all 3-point heads from 12.5m. The precision ratchet stop mechanism will ensure consistent force with incredible repeatability eventhough the interpolation were done by different operator.

Featuring the NEW Bowers ‘FASTFIT’ measuring heads with extended measuring range (above 14mm), the Bowers Ultima introduce a practical lever operation and faster gaging result by its digital screen. Furthermore, you can also do improvised measurement with extensions shaft for deep hole measurement above 6mm. Thanks to its 3 point "touching" anvils, Bowers Ultima Bore Gauge - Sets offer higher accuracy than conventional air micrometer on measuring grooves, threads, splines, deep-bores, internal cladding or weld and many more.

Your investment in Bowers Digital Bore Gauge NEW XT3 Series will be paid off quickly as you can now working with higher precision project as in vertical bores, pipes, cylindrical exhaust system and inner tubes with busy queue. Each packages are delivered with sets of traceable certificate for your ultimate precision.



Bowers Digital Lever Bore Gauge XTL Series Features:



">
