SPESIFIKASI Sylvac Metrology Data Cables & Probe Output

Sylvac Data Cables & Probe Output Ordering Guide:


Code No.DescriptionCable Length
OutputFunctionsPC Connectivity
804-1211 Sylvac D110V Connection Cable 2 Sylvac D110V - D100S/ D200S   N/A
901-5002 Replacement Sylvac Probe Cable 1.5 P10   N/A
901-5012 Replacement Sylvac Probe Cable 1.5 P25   N/A
901-5022 Replacement Sylvac Probe Cable 1.5 P50   N/A
901-5032 Replacement Sylvac Probe Cable 1.5 P10L   N/A
901-5042 Replacement Sylvac Probe Cable 1.5 P2B [Pre 2011]and P5   N/A
901-5052 Replacement Sylvac Probe Cable 1.5 P2BL and P5L   N/A
901-9993 Extension Cable (affects accuracy calculation) 3 All Sylvac Probes   N/A
904-4101 Foot pedal 2 D50S, D60S, D80S, D100S, D104PC, D300S, D302, D304, D70S, D400S All Z Cal, V Series and Altia Height Gauges   N/A
904-4102 Footswitch 2 Sylvac D70I, D70H only   N/A
905-4516 Powered Serial Data Output Cable 2 All IP65 Opto Outputs Bi Directional Connectivity 9 Pin Female
905-4519 Sylvac Powered Opto Duplex 15 All IP65 Opto Outputs Bi Directional Connectivity 9 Pin Female
925-1143 Sylvac Power Booster with Footswitch (for Bi-Directional Cables Only) 3 for RS232 Cable Continuous Power Supply 9 Pin Female
925-1151 Sylvac Power Booster 2 for RS232 Cable Continuous Power Supply 9 Pin Female
925-5608 RS232 connecting cable 2 D50S, D60S, D80S, D100S, D104 PC, All Z Cal Height Gauges, Diavite (Up to DH7) Trimos V & VL Series, Altia, Altia Premium, Trimos Horizon H series, Sylvac MBus, 55-2045-AEP column Bi Directional Connectivity 9 Pin Female
925-5609 Straight Connection 9 Pin Male - 9 Pin Female 3 D50S, D60S, D80S, D100S, D104 PC, All Z Cal Height Gauges, Diavite (Up to DH7) Trimos V Series, Altia, Altia Premium, Trimos Horizon H series, Sylvac MBus, 55-2045-AEP column Bi Directional Connectivity 9 Pin Female
926-5516 Sylvac Power Supply (To replace battery) 3 All (Non IP65) Opto outputs   N/A
926-5520 Sylvac Opto Simplex 15 All (Non IP65) Opto outputs Data Send Only 9 Pin Female
926-5521 Sylvac Opto Simplex Serial Data Cable 2m All (Non IP65) Opto outputs Data Send Only 9 Pin Female
926-5521A Sylvac Opto Simplex with Footswitch 2 All (Non IP65) Opto outputs Data Send Only 9 Pin Female
926-6001 Mini USB - USB 2 Sylvac Hi-cal   USB Receiver
926-6521 Sylvac Opto Duplex 2 All (Non IP65) Opto outputs Bi Directional Connectivity 9 Pin Female
926-6521A Sylvac Opto Duplex with Footswitch 2 All (Non IP65) Opto outputs Bi Directional Connectivity 9 Pin Female
926-6535 Sylvac Opto Duplex 15 All (Non IP65) Opto outputs Bi Directional Connectivity 9 Pin Female
926-6538 Sylvac Opto Duplex (Right Angle Opto Entry) 3 All (Non IP65) Opto outputs Bi Directional Connectivity 9 Pin Female
926-6539 Sylvac Opto Duplex (Left Angle Opto Entry) 3 All (Non IP65) Opto outputs Bi Directional Connectivity 9 Pin Female
926-6542 Sylvac Opto Duplex (Right Angle Opto Entry) 15 All (Non IP65) Opto outputs Bi Directional Connectivity 9 Pin Female
926-6543 Sylvac Opto Duplex (Left Angle Opto Entry) 15 All (Non IP65) Opto outputs Bi Directional Connectivity 9 Pin Female
926-6621 Sylvac Opto Duplex 2 All (Non IP65) Opto outputs Bi Directional Connectivity USB
926-6721 Sylvac Proximity USB 3 All IP67 Proximity Outputs Bi Directional Connectivity USB
926-6723 Proximity Serial Data Output Cable 3 All IP67 Proximity Outputs Bi Directional Connectivity 9 Pin Female
926-6821 Powered Opto / USB 2 All IP65 Opto Outputs Bi Directional Connectivity USB
926-7020 USB Footswitch 2 Metre Software Wedge, Sylconnect, VMux
926-7021 Heavy Duty USB Footswitch
926-8010 Sylvac Opto Digimatic (Mitutoyo) Sylvac MUX BOX ONLY 2 All (Non IP65) Opto outputs Bi Directional Connectivity Digimatic
926-8116 Sylvac 9 Pin Female to Digimatic 2 D50S, D60S, D80S, D100S, D104 PC, All Z Cal Height Gauges, Diavite (Up to DH7) Trimos V Series, Altia, Altia Premium Height Gauges and Trimos Horizon H series Bi Directional Connectivity Digimatic
926-8154 Sylvac Powered Opto Digimatic (Mitutoyo) 2 All IP65 Opto Outputs Bi Directional Connectivity Digimatic
926-8158 Sylvac Opto Digimatic (Mitutoyo) 2 All (Non IP65) Opto outputs Bi Directional Connectivity Digimatic
926-USB Serial to USB adaptor 0.01 RS232 Cable Converts Serial Output to USB USB
W-TA510 Impact HT to PC 2 Impact Series to PC Data Send Only 9 Pin Female
W-TR-200CA CVI TR200 Surface Finish Tester (Included with Tester) 2 TR200 to PC Data Send Only 9 Pin Female
W-WRT150PC CVI WRT150 (CVR135) Surface Finish Tester 2 WRT150 (CVR150) to PC Data Send Only 9 Pin Female



Dapatkan Penawaran Harga

Silahkan isi formulir di bawah ini untuk mendapatkan penawaran harga terbaik dari tim kami,

Sylvac Metrology Data Cables & Probe Outputs ia a great support for reliable gauging applications. They are compatible with various brands other than Sylvac like, Ojiyas, Trimos, Bowers and Kafer to name a few. The standardized format used on each instrument allows it to connect to PC for data capture and processing.

Sylvac data cable range from the very simple, robust devices such as hand tools and gauging centres, to the complex probes such as pneumatic and inductive probes, which are sophisticated, expensive, and fragile. For example; you can use the Sylvac OPTO-RS cable interface to convert the output of the dial gauge to a RS232 signal. Simply plug one end of the cable into the dial gauge and the other into a COM port of the PC.

The standardized design enables passive probes from any manufacturer to be used with specialized features such as the automatic readout adjustment. Each cables are properly sealed, impedance protected and safe for immediate application. The wide range of connectivity makes the Sylvac instruments are compatible with the majority of data acquisition systems, RS232, USB or Wireless data.

Sylvac Metrology Data Cables & Probe Output Features:

">
