Sylvac Digital Micrometer S_Mike PRO IP67
Segera Hubungi Kami :
(62) 778 408 6403
(62) 815 3611 0114
sales@lfc.co.id
Sylvac External Micrometer S_Mike PRO is manufactured in conformity with DIN 863. It enables users to conveniently interpolate measurements which allows for repetitive readings and better sensor lifetime usage. The main body frame is made of stainless steel with smooth grey enamel finish for protection against corrosion, scratch and temperature difference which can cause fluctuations in accuracy, especially in an open-design fabrication yard. The innovative Sylvac External Micrometer S_Mike Pro works by using a precision ratchet mechanism which ensures constant force is applied to provide a consistent gaging for every interpolation of the measurement. Furthermore, you can also send the measured data via Bluetooth connection to either smartphones or computer spreadsheet software within a 20-meter radius. You can also use this device for improvised gaging rig with Sylvac's gaging multiplexer software.
Product Features:
- Automatic wake-up by moving the measuring spindle (system S.I.S)
- Sleeping mode after 20 min. of non-usage. S.I.S
- Position memorized in sleeping mode. S.I.S
- Water protected for heavy-duty work with coolants and lubricants, protection rating IP67 according to IEC 60529, with or without connector
- Measuring range 0-102 mm covered with 3 instruments only (0-30, 30-66, 66-102)
- Quick displacement of the measuring spindle 12 mm / rotation
- Adjustable measuring force 5N / 10N for high repeatability and reproducibility
- Battery life: 12’000 hours continuous
- Thimble made of Delrin® a highly crystalline engineering thermoplastic by DuPont that specified for high load mechanical applications, high stiffness, low friction and excellent dimensional stability
SPESIFIKASI Sylvac Digital Micrometer S_Mike PRO IP67
Sylvac Digital Micrometer Dimensions:
Sylvac Digital Micrometer S_Mike PRO Ordering Guide:
| 903.0300 | 903.0600 | 903.1000 | ||
| Measuring range | mm | 0-30 | 30-66 | 66-102 |
| Max error G 1) | µm | 3 | 4 | 5 |
| Repeatability 2) | µm | 1 | 1 | 1 |
| Anvil types | Ø6.5 | Ø6.5 | Ø6.5 | |
| A | mm | 38.5 | 74.5 | 110.5 |
| B | mm | 27.5 | 43 | 60 |
| C | mm | 63 | 75 | 75 |
| D | mm | 11.5 | 12.5 | 13.5 |
| E | mm | 63 | 85 | 106 |
| F | mm | 176 | 231 | 270 |
| S_Connect: Proximity | USB / RS232 / Digimatic / Wireless 3) | |||
| IEC 60529 protection | IP67 with or without connector | |||
| Setting by PC | Yes | |||
| Adjustable measuring force | 5N / 10N | 10N (5N on demand) | ||
| Non-rotating spindle | Yes | |||
| Fast movement | Yes | |||
| PRESET | Yes | |||
| Smart Inductive Sensor | Yes | |||
1) according to DIN 863
2) ± 1 digit
3) Sylvac cables. See accessories category
