DoALL DCDS-600SA Dual Column Semi-Automatic Bandsaw

The DoALL DCDS-600SA high production semi-automatic, dual column, dual mitering metal cutting band saw offers up to 24” wide by 17” tall (600mm x 440mm) rectangular cutting capacity and 18.5″ round tube capacity.

A wide variety of materials can be easily turned into parts, including, but not limited to, structural materials, stainless and tool steel. The DoALL DCDS-600SA band saw has a Mitsubishi touch screen display controller for easy operation. The operator is isolated from the sawing operations, which reduces the likelihood of injury on the job.

This hydraulically controlled dual column, semi-automatic metal cutting band saw has a double-swivel head that is able to miter/angle cut at 60° both left and right. The saw blade is set at 7° cantilever, allowing for more efficient cutting. The DCDS-600SA is the ideal machine for a fabricator cutting multiple angles in the same work piece. The DCDS-600SA offers high loading capacity and a variety of optional accessories to configure the machine to meet nearly any application.

Standard Equipment

Hydraulic dual swivel head to 60 left to 60 degrees right
Rapid head down approach
Carbide faced saw guide inserts
Programmable material height sensor
Full stroke hydraulic vise
Driven band cleaning brushes
Infinite band speed controlled by variable frequency drive
Automatic movable guide arm setting
Cast Steel band wheels
Vertical hold down
Laser line generator
Recirculating coolant system
Mist band lubricator system
Digitally displayed angle position with hydraulic lock
Variable Vise Pressure
7 degree cant design
Saw blade guards
Operation and parts manuals on USB stick
Recommended band speed chart
One (1) complimentary DoALL Bi Metal saw blade
Complimentary DoALL Cutting Fluids package

SPESIFIKASI DoALL DCDS-600SA Dual Column Semi-Automatic Bandsaw

Saw blade (W x L)	1-1/4" x 238"
Band speed	65-328 fpm
Band tension	Hydraulic
Machine capacity (W x H)	600mm x 440 mm
Round tube	18,5" (470 mm)
Solid tube	8" (205 mm)
Production level	Extreme duty
Weight	3,715 lbs
Dimensions (L x W x H)	70" x 115" x 85"
