Sylvac S_Dial Mini Digital Indicator

Segera Hubungi Kami :

(62) 778 408 6403

(62) 815 3611 0114

sales@lfc.co.id

Sylvac S_Dial Mini is the smallest digital comparator available in the market, with a compact ∅45 mm non-rotating housing. Sylvac's gauges are equipped with the famous Sylvac measuring system known worldwide for its precision and low consumption. Sylvac S_Dial Mini is ideal for integration into machines or various measuring fixtures. The Protected version comes with a bellows-protected spindle without a lifting cap, while the Standard version comes without bellows, with or without a lifting cap.

Sylvac S_Dial Mini Features :

  • New design and larger display for better reading
  • <<Smart>> version with wireless Bluetooth technology (with 3 profiles Simple, Paired or HID)
  • Analog scale on <<Smart>> models
  • Standard execution IP54 and Protected execution IP67
  • Digital display resolution 0.01 / 0.001 mm with analogue scale
  • Measuring range: 12.5 mm

 Sylvac S_Dial Mini model

SPESIFIKASI Sylvac S_Dial Mini Digital Indicator

Sylvac S_Dial Mini Dimensions:

Sylvac S_Dial Mini dimensions

Sylvac S_Dial Mini Ordering Guide:

 Basic   805-4121 805-4125 805-4521 805-4525
 Measuring range  mm 12.5
 Analog scale  -
 Resolution  mm 0.01 0.001
 Execution 3) S P S P
 Max. Error fe  µm 10 1) 4
 Repeatability  µm 2
 Measuring force 2)  N 0.5 - 0.90 N 0.6 - 1.3 N 0.5 - 0.90 N 0.6 - 1.3 N
 Zero setting
 Resolution selection -
 PRESET = (max. ±999.99 mm) • 4)
 Min/max/delta display -
 Selection of measuring direction
 Multiplication factor -
 Output data USB / RS232
 IP rating IP54 IP67 IP54 IP67



 Smart   805-6121 805-6123 805-6125 805-6521 805-6523 805-6525
 Measuring range  mm 12.5
 Analog scale
 Resolution  mm 0.01 0.001
 Execution 3) S S P S S P
 Max. Error fe  µm 10 1) 4
 Repeatability  µm 2
 Measuring force 2)  N 0.5 - 0.90 N 0.5 - 0.90 N 0.6 - 1.3 N 0.5 - 0.90 N 0.5 - 0.90 N 0.6 - 1.3 N
 Lifting cap
 Zero setting
 Resolution selection
 PRESET = (max. ±999.99 mm)
 Min/max/delta display
 Selection of measuring direction
 Multiplication factor
 Output data Bluetooth® wireless technology / USB / RS232
 IP rating IP67



1) ±1 digit

2) Values ±20%, indicator in vertical position, outgoing measuring spindle

3) S=Standard, P=Protected

4) Preset configuration only by computer
