Non-contact Uncured Powder Thickness Gage

Affordably measures uncured powder coatings using non-contact ultrasonic technology to predict a cured thickness

PosiTest PC

Simple

  • Dedicated stand-alone unit is ready to measure right out of the box
  • Up to 4x faster measurement speed* — ideal for moving lines and swinging parts
  • Easy-to-read digital display with a simple, icon based menu
  • Hand-held, battery operated
  • Ergonomic and lightweight
  • No calibration adjustment required for most powders
  • Target Grid simultaneously displays distance to the part and alignment, making measurements easy
  • RESET features instantly restores factory settings

Durable

  • Solvent, acid, oil, water and dust resistant — ideal for harsh powder coating environments
  • Hard-shell carrying case included
  • Replaceable screen protects the sensor
  • Two year warranty

Accurate

  • Improved sensor technology allows easier measurement on small tubes, odd shapes and moving parts
  • Easy 1 and 2 point calibration adjustment options with Cal Reset to improve accuracy on unusual powders or substrates
  • Conforms to ASTM D7378

Versatile

  • No cable to risk disturbing the applied powder
  • Mils/microns switchable
  • High contrast color display
  • Adjustable display brightness for optimal visibility in any environment
  • Toggle sound On and Off
  • Uses alkaline or rechargeable batteries

Powerful

  • Storage of 999 readings with onscreen averaging. Stored readings can be downloaded to Posisoft Desktop software
  • Scan Mode continuously takes measurements - ideal for analyzing large areas
  • USB Keyboard Mode emulates keystrokes to easily stream readings to a PC or PLC
  • USB port for fast, simple connection to a PC and to supply continuous power
  • Software updates keep your instrument current

LFC is the authorized distributor for DeFelsko in Singapore and Indonesia. Contact us to purchase the PosiTecst PC or any other DeFelsko products.

SPESIFIKASI DeFelsko PosiTest PC Powder Checker

PosiTest PC Technical Specifications:

Range
20 – 100 μm (0.8 – 4.0 mils)
Resolution
1 μm (0.1 mil)
Accuracy
±5 μm (± 0.2 mil)
Measurement Time
1 – 3 seconds
Measurement Distance to Powder
19 mm (0.75 inch)
Measurement Area
2 mm (0.8 inch)
Size

241 x 64 x 51 mm
(9.5" x 2.5" x 2.0")

Weight
180 g (6.4 oz.) without batteries



PosiTest PC Ordering Guide:

PosiTest PC Ordering Guide
