Käfer Compact Dial Gauge M2T DIN EN ISO 463

Segera Hubungi Kami :

(62) 778 408 6403

sales@lfc.co.id

SPESIFIKASI Käfer Compact Dial Gauge M2T DIN EN ISO 463

Käfer Compact Dial Gauge M2T IP 67 DIN EN ISO 463 Dimension:



Käfer Compact Dial Gauge M2T DIN EN ISO 463 Ordering Guide:



Model no.

Graduations

Range

Dial Ø

Total error

Stem Ø

Notes

M 2 T Basic

0.01 mm

10 mm

58 mm

17 µm

8 mm

4 mm ø spindle

M 2 TS

0.01 mm

10 mm

58 mm

17 µm

8 mm

4 mm ø spindle
shockproof and
ruby ball point

M 2/10 T

0.01 mm

10 mm

58 mm

25 µm

8 mm

5 mm ø spindle

M 2/20 T

0.01 mm

20 mm

58 mm

25 µm

8 mm

5 mm ø spindle

M 2/30 T

0.01 mm

30 mm

58 mm

25 µm

8 mm

5 mm ø spindle

M 2/50 T

0.01 mm

50 mm

58 mm

25 µm

8 mm

5 mm ø spindle



Dapatkan Penawaran Harga

Silahkan isi formulir di bawah ini untuk mendapatkan penawaran harga terbaik dari tim kami,

Käfer Compact Dial Gauge M2T DIN EN ISO 463 is a Precision Dial Gauge with extended stem and counter clockwise reading. The classic Kafer dial gage model M2T comes with flat back and steel point with 10 mm range. All details of this Dial Gauge conform to DIN 878 in conjunction with DIN EN ISO 463. A well thought-out design, the use of high-quality components and materials as well as the precision engineered mechanism guarantee the outstanding quality of the Precision Dial Gauge M 2 T. This applies not only to the outside dimensions but also to allowed tolerances, the measuring force and the measuring force reversal range. Spindle and stem are made of resistant stainless steel. The spindle is lapped.

Features :

Benefits :

">
